T0-FP750
High Quality Mini PC
AMD Ryzen™ 9 6900HX
AMD Ryzen™ 5 6600H
DDR5-5600Hz up to 64GB
2xM.2 SSD up to 4TB
Triple Display: 4K/8K
AMD Radeon™680M/660M
WiFi6
Bluetooth5.2
Advanced Cooling System
Windows11 Pro Inside
Unboxing Video
AMD Ryzen™ 9 6900HX Processor Beckmarks
AMD Ryzen™ 5 6600H
3DMark Time Spy Benchmark
Radeon™ Graphics 680M
AMD RDNA™ 2 Architecture
All in one USB 4.0
Triple Monitors
The T0-FP750 Ryzen Mini PC supports triple display functionality, making it ideal for multitasking, gaming, and professional work such as video editing and programming.
Gaming Performance
Our setup includes Windows 11 Pro 64-bit, an AMD Ryzen 7 6900HX processor with 8 cores and 16 threads on a 4 nm process, a 512GB FORESEE XP2100 SSD for fast storage, and a 21.7-inch LG 22M35 monitor with a 1920×1080 resolution at 60Hz. It also features 32 GB of Crucial DDR5 RAM, optimized for smooth gaming performance and efficient FPS testing.
Network Speed
With WiFi 6 or 6E, Bluetooth, and 2.5GbE, these advanced networking features ensure efficient and seamless work performance.
2xDDR5 RAM
Supports up to 64GB of memory with a frequency of 5600MHz or 4800MHz, and features 2 M.2 slots for 2280 NVMe SSDs (up to 4TB storage capacity, i.e., 2x 2TB SSDs). Additionally, an extra M.2 slot is available for Wi-Fi and Bluetooth module upgrades, providing flexibility for customization and meeting the demands of large memory workloads and fast network entertainment experiences.
MT2.5 Cooling Fan Tech.
The MT2.5 edition features advanced cooling technology and design, including a top air intake, built-in copper heat pipes, and a vortex fan. This design ensures efficient cooling, keeping the mini PC cool and stable even under high loads of up to 45W, while maintaining minimal fan noise.
Compact and Fully I/O Ports
570g compact T0-FP750 Ryzen Mini PC offers a full range of I/O interfaces, allowing easy connection to various data transfer and display devices.
For Your Every Need
Creating
Design with ease and precision
Working
Supercharge your productivity
Educating
Elevate your learning journey
Entertaining
4K/8K movies
Quality Assurance Guarantee
Our commitment to rigorous quality control and comprehensive reliability testing sets us apart. With a 168-hour aging test and thorough factory inspections for data packet loss, we ensure that every unit meets the highest standards. Trust in our dedication to providing peace of mind for each customer.
What’s in the box
Maxtang T0-FP750
User Manual
HDMI® Cable
Power Adapter
VESA
Mounting Screws
Power Cord
Mouse Pad Gift
what’s In The Box
1 x Maxtang MiniPC T0-FP750
1 x Power Adapter
1 x HDMI® Cable
1 x Wall-mounted Bracket
1 x Mouse Pad Gift
*Product has High-Definition Multimedia Interface.
*The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
*All data is for information purposes only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate however, no responsibility is assumed for inaccuracies. All other trademarks or registered trademarks are the property of their respective owners and are recognized.
T0-FP750 Specifications
T0-FP750 Mini PC Gaming with AMD® Ryzen™6000/7000 FP7r2 Series Processors with Radeon™ Graphics
| T0-FP750 | CPU | Ryzen™ 9 6900HX | Ryzen™ 7 8845HS | Ryzen™ 7 7840HS | Ryzen™ 7 7735HS | Ryzen™ 5 6600H | ||||||
| Cores/Threads | 8C/16T | 8C/16T | 8C/16T | 8C/16T | 6C/12T | |||||||
| Max. Boost Clock | 4.9GHz | 5.1GHz | 5.1GHz | 4.75GHz | 4.5GHz | |||||||
| Base Clock | 3.3GHz | 3.8GHz | 5.1GHz | 3.2GHz | 3.3GHz | |||||||
| L3 Cache | 16MB | 16MB | 16MB | 16MB | 16MB | |||||||
| Display Graphics | 680M | 780M | 780M | 680M | 660M | |||||||
| Display via | 1xHDMI®2.0,DisplayPort 1.4 and 1xUSB-C(Type-C port, USB4) full-funcationed, support display mode. | |||||||||||
| BIOS | AMI UEFI BIOS | |||||||||||
| Memory | Dual Channel SO-DIMM DDR5 up to 64GB | |||||||||||
| Ethernet interface | 1xRJ45 LAN(2.5GbE) | |||||||||||
| Controller | Intel i226. Data Rate Per Port: 10/100/1000/2500Mbps | |||||||||||
| Display GPU | AMD Radeon™ Graphics | |||||||||||
| Audio Codec | CONEXANT HD CX20632 | |||||||||||
| Hardware Function | CPU temperature, System temperature, Onboard voltage, Watchdog | |||||||||||
| Storage | 2xM.2 Slot for 2280 NVMe SSD | |||||||||||
| Expansion | 1xM.2 Slot for WiFi, Support PCIe&USB | |||||||||||
| Front I/O | USB3.2 | 2xUSB3.2(Type-A port) | ||||||||||
| USB-C | 1xUSB-C(Type-C port), support USB 3.2_10Gb ONLY | |||||||||||
| Audio | 1xCTIA 2in1 Audio Jack, Supports Line-out+Mic-in | |||||||||||
| Power Button | 1xPower Button | |||||||||||
| Back I/O | LAN | 1xRJ45 LAN(2.5GbE) | ||||||||||
| USB-C | 1xUSB-C(Type-C port, USB4) full-funcationed, support display mode. | |||||||||||
| USB2.0 | 1xUSB2.0 | |||||||||||
| DP | 1xDP1.4 | |||||||||||
| HDMI2.0 | 1xHDMI2.0 | |||||||||||
| DC-IN | 1xDC-IN | |||||||||||
| Others | TPM | Optional | ||||||||||
| Dimension | Size | 127 mm x 135 mm x 55mm (L x W x H) | ||||||||||
| Power | Standard Port | 19V/20V DC-in | ||||||||||
| Temperature | Operating Temp. | 0°C to 50°C | ||||||||||
| Storage Temp. | -20°C to 70°C | |||||||||||
| Cooling | Active | |||||||||||
| Operating System | Supports Windows 10/11 64bit, Linux 64bit | |||||||||||
| *All specifications and photos are subject to change without notice. | ||||||||||||
